West:
Features
- Allows for two temperature zones in one trailer without adding remote evaporators
- CARB Evergreen
- No need for Diesel Particulate Filter (DPF)
- Delivers double-digit fuel savings
- Superior temperature control
- Electronic fuel injection with real-time fuel monitoring and recording
- >25 horsepower engine
Features
- Allows for two temperature zones in one trailer without adding remote evaporators
- CARB Evergreen
- No need for Diesel Particulate Filter (DPF)
- Delivers double-digit fuel savings
- Superior temperature control
- Electronic fuel injection with real-time fuel monitoring and recording
- >25 horsepower engine
Refrigeration Capacity
- (System net cooling capacity at 100°F ambient and high speed engine operation)
- Engine Power w/ETV: 35° F: 55,000 BTU/hr; 16,118 Watts
- Engine Power w/ETV: 0° F: 30,000 BTU/hr; 8,792 Watts
- Engine Power w/ETV: -20° F: 18,000 BTU/hr; 5,275 Watts
- Electric Power: 35° F: 49,000 BTU/hr; 14,360 Watts
- Electric Power: 0° F: 28,000 BTU/hr; 8,204 Watts
- Electric Power: -20° F: 17,000 BTU/hr; 4,981 Watts
Heating Capacity
- (System net heating capacity at 35/0°F ambient)
- BTU/hr: 39,000
Airflow
- Volume at 0 Pa static pressure: Combined zone 1 + zone 2 = 2,850 ft³/min
Engine
- Engine: Four cylinder, direct injection, liquid cooled
- Model: TK488CR
- RPM at High Speed: 2,050
- RPM at Low Speed: 1,250
- Hp Rating at 2,050 RPM: 33
- Oil Capacity: 12 qt
- Maintenance Interval: 3,000 hrs/4,000 hrs
Compressor
- Lightweight aluminum alloy body, heads and deep sump
- Model: X430L
- Displacement: 30.0 in³
Refrigerant
- Type: (Zero Ozone Depletion Potential (ODP), internationally approved) R404A
- Charge: 16.5 lbs
System Weight
- System Weight: 1,919 lbs
- 50 gallon fuel tank w/bracket: 76 lbs
Specs
Capacities
- Refrigeration Capacity: 55,000 BTU/hr (16,118 Watts)
- Heating Capacity: 39,000 BTU/hr
Airflow
- Airflow Volume: Combined zone 1 + zone 2 = 2,850 ft³/min
Engine
- Engine Type: Four cylinder, direct injection, liquid cooled
- Engine Model: TK488CR
- Engine Rating: 33 hp
- Maintenance Intervals: 3,000 hrs/4,000 hrs
General
- Weight: 1,919 lbs
- Dimensions: 81.6″ x 86.2″ x 24″
Refrigeration Capacity
- (System net cooling capacity at 100°F ambient and high speed engine operation)
- Engine Power w/ETV: 35° F: 55,000 BTU/hr; 16,118 Watts
- Engine Power w/ETV: 0° F: 30,000 BTU/hr; 8,792 Watts
- Engine Power w/ETV: -20° F: 18,000 BTU/hr; 5,275 Watts
- Electric Power: 35° F: 49,000 BTU/hr; 14,360 Watts
- Electric Power: 0° F: 28,000 BTU/hr; 8,204 Watts
- Electric Power: -20° F: 17,000 BTU/hr; 4,981 Watts
Heating Capacity
- (System net heating capacity at 35/0°F ambient)
- BTU/hr: 39,000
Airflow
- Volume at 0 Pa static pressure: Combined zone 1 + zone 2 = 2,850 ft³/min
Engine
- Engine: Four cylinder, direct injection, liquid cooled
- Model: TK488CR
- RPM at High Speed: 2,050
- RPM at Low Speed: 1,250
- Hp Rating at 2,050 RPM: 33
- Oil Capacity: 12 qt
- Maintenance Interval: 3,000 hrs/4,000 hrs
Compressor
- Lightweight aluminum alloy body, heads and deep sump
- Model: X430L
- Displacement: 30.0 in³
Refrigerant
- Type: (Zero Ozone Depletion Potential (ODP), internationally approved) R404A
- Charge: 16.5 lbs
System Weight
- System Weight: 1,919 lbs
- 50 gallon fuel tank w/bracket: 76 lbs
Specs
Capacities
- Refrigeration Capacity: 55,000 BTU/hr (16,118 Watts)
- Heating Capacity: 39,000 BTU/hr
Airflow
- Airflow Volume: Combined zone 1 + zone 2 = 2,850 ft³/min
Engine
- Engine Type: Four cylinder, direct injection, liquid cooled
- Engine Model: TK488CR
- Engine Rating: 33 hp
- Maintenance Intervals: 3,000 hrs/4,000 hrs
General
- Weight: 1,919 lbs
- Dimensions: 81.6″ x 86.2″ x 24″
